The most professional roll forming machine and light gauge steel framing roll forming machine manufacturer
3 Years
| Ask Lasest Price | |
| Brand Name : | JCX |
| Model Number : | standing seam roll forming machine |
| Certification : | CE and ISO |
| Price : | according to your profile drawing we will offer you the best price |
| Payment Terms : | L/C, T/T, Western Union |
| Supply Ability : | 30 SETS roll forming machine |
| Delivery Time : | 20 working days |
380V 50Hz Standing Seam Roofing Sheet Roll Forming Machine Long Time Service
1.Application of Standing Sem Roll Forming Machine:
2.Main componets of Standing Seam Roll Forming Machine:
| Manual Decoiler | 1 Set |
| Feeding guiding device | 1 Set |
| Leveling System | 1 Set |
| Roll Forming System | 1 Set |
| Hydraulic Cutting System | 1 Set |
| PLC control box | 1 Set |
| Hydraulic Unit | 1 Set |
| Receiving Tables | 1 Set |
3.Machine picture of Standing Seam Roll Forming Machine:
4.Machine specification of Standing Seam Roll Forming Machine
| Machine Specifications | |
| Weight | About 1.25tons |
| Size | About 2.2*1.15*1.3m(length x width x height) |
| Color | Main color: blue or as your requirement |
| Material | Color Steel Coils |
| Thickness | 0.3-0.7 mm |
| Yield Strength | 235Mpa |
| Quantity of forming rollers stations | 8 |
| Diameter of forming rollers shafts | 70mm |
| Roll Forming Speed | 10-15m/min |
| Forming rollers material | No.45 steel, coated with chromed treatment |
| Cutter material | Cr12 steel, with quenched treatment |
| Controlling system | PLC and Converter |
| Electric Power requirement | Main motor power: 2.2kw hydraulic motor |
5.Our service
A. Foreign debugging
If you need, we will arrange our professional engineers to help you install and debug the machines well. Buyer should pay $60 per day
B. Guarantee period
The warranty will be maintenance, maintain in the guarantee period of 18 months starting from delivery. Because of the quality of equipment during guarantee period, we will provide the parts free of charges, which is in the conditions of correct operation. (Natural disasters or factors which can’t forced by human are excluded).
C. Training
During installation and adjustment of the equipment, our engineers shall provide the training to
buyer’s personnel request to operate and maintain the equipment. Including foundation construction, electrical works, hydraulic oil, safe operation and non-standard safety items, testing material and etc.
D. Lifetime services
Life time services to every customer.
Q1. What are the main key points for selecting right machines?
A1: Whole structure,Roller Shaft,Roller Material,Motor&Pump,and Control system. As the new buyer, please kindly know that price not the final point.
Good quality is for long-term business cooperation.
Q2. Can you provide OEM service for roll forming machine?
A2: Yes, most of cold roll forming machine need to be customized as detailed request, because raw material , size , production usage, machine speed, then machine specification will be some different.
Q3. What’s your standard trade terms ?
A2: We can provide the technical offer with FOB,CFR,CIF,Door to Door and so on. Please kindly tell the detailed port name for competitive ocean freight.
Q4. How about the quality control?
A4: Our company adopts 6S system to control every part with passed ISO9001:2000, CE,TUV/BV(.) Certificate.
Q5. How about the after-sale service?
A5: We provide 15 months free warranty and free technical support for the whole life of any machine. During warranty period, if parts still broken, we can send the new ones freely.
Q6. If I am in Beijing,Shanghai or Guangzhou,how to visit your company?
A6: 1) Beiing South Statioin to Cangzhou West Station (by fast train 1 hour).
2) Shanghai Hongqiao to Cangzhou West (4.5 hours)
3) Guangzhou Airport to Tianjin ,then Tianjin to Cangzhou West
When you arrive our station, we will arrange to pick up you there!
|
|
